Unistrut P2679 Swivel Nut
Unistrut P2679 - Swivel Nut

Unistrut

Unistrut P2679 - Swivel Nut

$0.00
Sold out
Item Code:P2679-4
Order Size:Single Piece
Quantity:
Beam Clamp Swivel Nut P2679 is to be used when attaching Unistrut beam clamps to a sloped or angled beam.


Features:

  • For sloped or angled beams
  • Electrogalvanized for corrosion protection
  • Threaded rod sizes up to 1/2"
  • This series is available in Electrogalvanized (EG).



Materials & Finishes

Materials & Finishes - Standard:

  • Base Metal: Steel conforms to ASTM A1011 SS GR 33, A1011 HSLAS GR 45, A36, A575, A576, or A635.
  • Electrogalvanized (EG):  Conforms to ASTM B633, Type III SC1
  • Unistrut Defender (DF):  Conforms to ASTM A1059
  • Hot-Dipped Galvanized (HG):  Conforms to ASTM A123 or A153
  • Perma-Green (GR):  Conforms to commercial standards for powder coating
  • Perma-Gold (ZD):  Conforms to ASTM B633, Type II SC1 or SC3
  • Plain (PL):  No finish

Materials & Finishes - Special Metals:

  • Stainless Steel, Type 304 (SS):  Conforms to ASTM A240 or A276, Type 304 *
  • Stainless Steel, Type 316 (ST):  Conforms to ASTM A240 or A276, Type 316 *
  • Aluminum (AL):  Conforms to ASTM B209, Type 1100F or 5052-H32 *

* These materials have different physical properties and performance characteristics. Please contact us for design support.



P2679 CUT SHEET PDF DOWNLOAD
